Anycubic Photon Mono 2
The Anycubic Photon Mono 2 is an accessible compact MSLA printer featuring a 6.6-inch 4K+ monochrome LCD, upgraded LightTurbo Matrix illumination and a 143 × 89 × 165 mm build volume.
Already own this printer? Use the specifications and tested resin settings below, then explore Monocure3D MSLA resins for your next print.
The Anycubic Photon Mono 2 is a compact resin printer designed for straightforward desktop printing. Its 4K+ monochrome LCD provides 34 μm XY resolution, while the upgraded LighTurbo Matrix light source supports stable, uniform exposure. The laser-engraved build plate and 143 × 89 × 165 mm build volume suit miniatures, models and small prototypes. It uses 405 nm UV-curing resin and is compatible with Monocure3D MSLA resins. Begin with the SML profile and calibrate exposure for your chosen resin and print environment.
| Operation | 2.8-inch TFT touch-control |
|---|---|
| Printing Speed | Up to 50 mm/hr |
| Software | Anycubic Photon Workshop |
| Rated Power | 48 W |
| Connectivity | USB Type-A 2.0 |
| Printer Size | 229 × 235 × 390 mm |
| Technology | 6.6-inch 4K+ monochrome LCD (MSLA) |
| Build Volume | 143 × 89 × 165 mm (2.09 L) |
| Light Source | Upgraded LighTurbo Matrix |
| Material | 405 nm UV resin; Monocure3D MSLA resins recommended |
| XY Resolution | 4096 × 2560; 34 μm |
| Net Weight | 4 kg |
| Z-Axis Resolution | 10 μm |
- 6.6-inch 4K+ monochrome LCD with 34 μm XY resolution
- 143 × 89 × 165 mm build volume
- Upgraded LighTurbo Matrix illumination
- Laser-engraved build plate and USB workflow
- Compatible with Monocure3D 405 nm MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
