Anycubic Photon Mono M5
The Anycubic Photon Mono M5 combines a 10.1-inch 12K monochrome LCD with a 19 μm horizontal pixel size for exceptionally fine resin prints. Its generous build area and crisp 480:1 contrast ratio make it well suited to detailed miniatures, prototypes and production parts.
For dependable results, pair it with Monocure3D MSLA resins.
Anycubic Photon Mono M5 is an XL-format resin 3D printer designed for detailed, repeatable MSLA printing. 12K 10.1-inch monochrome LCD with 11,520 × 5,120 resolution. Fine 19 μm horizontal pixel size and 480:1 contrast ratio. Generous 200 × 218 × 123 mm build volume. USB and Wi-Fi connectivity with Anycubic Photon Workshop.
Recommended resin: Monocure3D MSLA resin selected for the printer's UV wavelength and application.
Original printer library record: https://old.monocure3d.com.au/printers/photon-mono-m5/
| Operation | 4.3-inch TFT touch control |
|---|---|
| Software | Anycubic Photon Workshop |
| Connectivity | USB Type-A 2.0 and Wi-Fi |
| Technology | 10.1-inch 12K monochrome LCD (MSLA) |
| Light Source | LED matrix UV light source |
| XY Resolution | 12K (11,520 × 5,120 px) |
| Z-Axis Resolution | Dual linear rails with 10 μm accuracy |
| Contrast Ratio | 480:1 |
| Printing Speed | 20–50 mm/h |
| Rated Power | 100 W |
| Printer Size | 460 × 270 × 290 mm |
| Build Volume | 200 × 218 × 123 mm |
| Material | Monocure3D MSLA resins and compatible 405 nm UV-curing resins |
| Net Weight | 8.6 kg |
- 12K 10.1-inch monochrome LCD with 11,520 × 5,120 resolution
- Fine 19 μm horizontal pixel size and 480:1 contrast ratio
- Generous 200 × 218 × 123 mm build volume
- USB and Wi-Fi connectivity with Anycubic Photon Workshop
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
