Anycubic Photon Mono M5s
The Anycubic Photon Mono M5s combines a 10.1-inch 12K monochrome LCD with a generous 218.88 × 122.88 × 200 mm build volume. Its levelling-free platform, automated checks and fast-printing capability make it a practical high-resolution MSLA printer for detailed models, prototypes and production work.
The Anycubic Photon Mono M5s is a high-resolution desktop resin printer built around a 10.1-inch 12K monochrome LCD. Its 218.88 × 122.88 × 200 mm build volume provides useful capacity for prototypes, miniatures, dental models and detailed production parts. Levelling-free operation, automated device checks, resin detection and Wi-Fi connectivity simplify setup and monitoring. For reliable results, use the linked XL starting profile with compatible Monocure3D MSLA resins and confirm exposure with a calibration model.
| Operation | 4.3-inch TFT touch-control |
|---|---|
| Software | Anycubic Photon Workshop; compatible with third-party slicers |
| Connectivity | USB 2.0 and Wi-Fi |
| Technology | 10.1-inch 12K monochrome LCD (MSLA) |
| Light Source | Matrix LED UV light source |
| XY Resolution | 11520 × 5120 pixels (approximately 19 × 24 µm) |
| Layer Height | 0.01–0.15 mm |
| Printing Speed | Up to 105 mm/hr with high-speed resin; approximately 70 mm/hr with general resin |
| Build Volume | 218.88 × 122.88 × 200 mm |
| Printer Size | 290 × 270 × 460 mm |
| Net Weight | 8.9 kg |
| Rated Power | 100 W |
| Recommended Material | Monocure3D MSLA resins |
- 10.1-inch 12K monochrome LCD with 19 × 24 µm XY resolution
- 218.88 × 122.88 × 200 mm build volume
- Levelling-free platform with automated device checks
- USB and Wi-Fi connectivity
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
