Anycubic Photon Mono X
The Anycubic Photon Mono X combines an 8.9-inch 4K monochrome LCD with a 192 × 120 × 245 mm build volume. Its 50 µm XY resolution, matrix UV light source and dual-rail Z axis make it a capable large-format MSLA printer for models, prototypes and small production runs.
The Anycubic Photon Mono X provides a spacious 192 × 120 × 245 mm build volume and a 4K monochrome LCD with 50 µm XY resolution. Its matrix UV light source and stable dual-rail Z-axis arrangement support consistent printing across the platform. Use the linked resin selector as a starting profile with compatible Monocure3D MSLA resins, then confirm normal exposure with a calibration model.
| Operation | 3.5-inch touchscreen |
|---|---|
| Software | Anycubic Photon Workshop; compatible with CHITUBOX and Lychee Slicer |
| Connectivity | USB |
| Technology | 8.9-inch 4K monochrome LCD (MSLA) |
| Light Source | 405 nm matrix UV light source |
| XY Resolution | 3840 × 2400 pixels (50 µm) |
| Layer Height | 0.01–0.15 mm |
| Printing Speed | Up to 60 mm/hr |
| Build Volume | 192 × 120 × 245 mm |
| Printer Size | 270 × 290 × 475 mm |
| Net Weight | Approximately 10.75 kg |
| Rated Power | 120 W |
| Recommended Material | Monocure3D MSLA resins |
- 8.9-inch 4K monochrome LCD
- 3840 × 2400 resolution with 50 µm XY pixel size
- 192 × 120 × 245 mm build volume
- Matrix UV light source and dual-rail Z axis
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
