Elegoo Saturn 2 8K
The Elegoo Saturn 2 8K pairs a 10-inch 8K monochrome LCD with a 218.88 × 123.12 × 250 mm build volume. Its COB 405 nm light source and 28.5 µm XY resolution support sharp, consistent printing across a spacious build platform.
The Elegoo Saturn 2 8K offers a balanced combination of resolution and build capacity. Its 10-inch 8K monochrome LCD delivers a 28.5 µm XY resolution across a 218.88 × 123.12 × 250 mm build volume. A 405 nm COB light source supports uniform curing, while the dual linear-rail Z axis is designed for stable movement. Use the linked XL starting profile with compatible Monocure3D MSLA resins and validate normal exposure before production printing.
| Operation | 3.5-inch touchscreen |
|---|---|
| Software | CHITUBOX |
| Connectivity | USB |
| Technology | 10-inch 8K monochrome LCD (MSLA) |
| Light Source | 405 nm COB light source |
| XY Resolution | 7680 × 4320 pixels (28.5 µm) |
| Layer Height | 0.01–0.20 mm |
| Printing Speed | 30–70 mm/hr |
| Build Volume | 218.88 × 123.12 × 250 mm |
| Printer Size | 305.9 × 273 × 567.3 mm |
| Net Weight | 11 kg |
| Power Requirements | 100–240 V AC; 24 V, 4 A output |
| Recommended Material | Monocure3D MSLA resins |
- 10-inch 8K monochrome LCD
- 28.5 µm XY resolution
- 218.88 × 123.12 × 250 mm build volume
- 405 nm COB light source
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
