Elegoo Saturn 3 Ultra 12K
The Elegoo Saturn 3 Ultra 12K features a 10-inch 12K monochrome LCD, 19 × 24 µm XY resolution and a 218.88 × 122.88 × 260 mm build volume. Wi-Fi transfer, a Linux-based system and a ball-screw Z axis support a fast and capable resin-printing workflow.
The Elegoo Saturn 3 Ultra 12K is designed for users who need fine detail without giving up useful build capacity. Its 10-inch 12K monochrome LCD provides a 19 × 24 µm XY resolution over a 218.88 × 122.88 × 260 mm build volume. A COB and refractive-lens light engine supports uniform exposure, while Wi-Fi transfer, a Linux operating system and an integrated ball-screw Z axis streamline operation. Use the linked XL profile as a starting point with Monocure3D MSLA resins.
| Operation | 4-inch IPS touchscreen |
|---|---|
| Software | CHITUBOX and Voxeldance Tango |
| Connectivity | USB and Wi-Fi |
| Technology | 10-inch 12K monochrome LCD (MSLA) |
| Light Source | COB light source with refractive lens |
| XY Resolution | 11520 × 5120 pixels (19 × 24 µm) |
| Layer Height | 0.01–0.20 mm |
| Printing Speed | Up to 150 mm/hr |
| Build Volume | 218.88 × 122.88 × 260 mm |
| Printer Size | 305.9 × 273 × 562.5 mm |
| Power Requirements | 100–240 V AC; 24 V, 7.5 A output |
| Recommended Material | Monocure3D MSLA resins |
- 10-inch 12K monochrome LCD with 19 × 24 µm XY resolution
- 218.88 × 122.88 × 260 mm build volume
- Maximum stated printing speed of 150 mm/hr
- USB and Wi-Fi file transfer
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
