Elegoo Saturn S 4K
The Elegoo Saturn S 4K uses a 9.1-inch 4K monochrome LCD with approximately 48 µm XY resolution and a 196 × 122 × 210 mm build volume. Its enhanced light source and stable Z-axis design make it a practical platform for detailed resin printing.
The Elegoo Saturn S 4K provides a useful combination of build capacity and detail for models, prototypes and production parts. Its 9.1-inch monochrome LCD offers 4098 × 2560 resolution and approximately 48 µm XY pixel size over a 196 × 122 × 210 mm build volume. Use the linked XL settings with compatible Monocure3D MSLA resins and calibrate exposure for the selected resin, colour and operating environment.
| Operation | 3.5-inch touchscreen |
|---|---|
| Software | CHITUBOX |
| Connectivity | USB |
| Technology | 9.1-inch 4K monochrome LCD (MSLA) |
| Light Source | 405 nm matrix UV light source |
| XY Resolution | 4098 × 2560 pixels (approximately 48 µm) |
| Layer Height | 0.01–0.15 mm |
| Printing Speed | 30–70 mm/hr |
| Build Volume | 196 × 122 × 210 mm |
| Net Weight | Approximately 10.9 kg |
| Recommended Material | Monocure3D MSLA resins |
- 9.1-inch 4K monochrome LCD
- 4098 × 2560 resolution with approximately 48 µm XY pixel size
- 196 × 122 × 210 mm build volume
- 30–70 mm/hr stated printing speed
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
