Phrozen Sonic Mighty Revo
The Phrozen Sonic Mighty Revo uses a 10.1-inch 14K monochrome LCD with 16.8 × 24.8 µm XY resolution and a 223 × 126 × 235 mm build volume. Assisted levelling, smart print monitoring and an integrated heater support a streamlined, reliable printing workflow.
The Phrozen Sonic Mighty Revo combines high-resolution printing with monitoring and workflow features intended to reduce setup and print failures. Its 10.1-inch 14K monochrome LCD delivers a 16.8 × 24.8 µm XY resolution over a 223 × 126 × 235 mm build volume. Assisted levelling, residue and failure detection, a chamber heater, USB and Wi-Fi connectivity and integration with the Phrozen GO app make it suitable for demanding creative and professional applications. Use the linked XL settings with compatible Monocure3D MSLA resins.
| Operation | 5-inch touchscreen |
|---|---|
| Software | CHITUBOX V2.1 or later; compatible with other supported slicers |
| Connectivity | USB and Wi-Fi |
| Technology | 10.1-inch 14K monochrome LCD (MSLA) |
| Light Source | Linear projection LED module |
| XY Resolution | 13320 × 5120 pixels (16.8 × 24.8 µm) |
| Layer Height | 0.01–0.30 mm |
| Printing Speed | Approximately 450 layers/hr |
| Build Volume | 223 × 126 × 235 mm |
| Printer Size | 353 × 345 × 517 mm |
| Net Weight | 18 kg |
| System Power | Maximum 240 W |
| Recommended Material | Monocure3D MSLA resins |
- 10.1-inch 14K monochrome LCD with 16.8 × 24.8 µm XY resolution
- 223 × 126 × 235 mm build volume
- Assisted levelling and smart residue/failure detection
- USB and Wi-Fi connectivity
- Compatible with Monocure3D MSLA resins
Dial in your resin for the best print results
Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.
