SHINING 3D AccuFab-L4D

SHINING 3D AccuFab-L4D

The SHINING 3D AccuFab-L4D is a versatile 4K dental resin printer created for clinics and laboratories. Its large 192 × 120 × 180 mm build volume, optional compact platform, advanced cooling and integrated AccuWare workflow support efficient models, guides, trays, gingiva masks and orthodontic production.

The open-material AccuFab workflow supports selected third-party photopolymer resins. Contact Monocure3D for compatible Monocure3D dental and MSLA/DLP resin recommendations, printer-specific starting profiles and calibration guidance.

Contact Monocure3D for current availability, a tailored quotation and compatible dental resin workflow advice.

For biocompatible or regulated dental applications, follow the resin manufacturer’s validated printing, washing and post-curing instructions and confirm the requirements applicable in your region.

The SHINING 3D AccuFab-L4D is a productive 4K dental printer for clinics and laboratories. Its 192 × 120 × 180 mm build volume supports efficient full-platform production, while a compact 70 × 70 mm ceramic platform and small tank are available for lower-volume clinical cases. SHINING 3D's District Cooling System keeps the working screen below 40°C to improve stability and service life. AccuWare provides automated layout, support and slicing tools for dental models, orthodontic models, surgical guides, custom trays and gingiva masks.

Technology 4K monochrome LCD dental resin printing
Resolution 3840 × 2400 pixels
Build Volume 70 × 70 × 150 mm or 192 × 120 × 180 mm
Print Speed Up to 50 mm/h, material and layer dependent
Accuracy ±0.05 mm under manufacturer test conditions
Layer Thickness 50, 75 or 100 µm
Platform Large and compact ceramic platform options
Cooling District Cooling System maintains the screen below 40°C
Connectivity USB, Wi-Fi and Ethernet
Printer Size 360 × 360 × 530 mm
Net Weight Approximately 19 kg
Software AccuWare with dental design modules and cloud control
Applications Dental and orthodontic models, guides, trays and gingiva masks
Recommended Material Contact Monocure3D for compatible dental resin profiles
  • Large 192 × 120 × 180 mm dental production volume
  • 4K 3840 × 2400 monochrome LCD resolution
  • Optional compact 70 × 70 mm ceramic platform and small resin tank
  • District Cooling System controls screen temperature
  • Open material ecosystem with certified third-party resin options

Dial in your resin for the best print results

Use our calibration models to fine-tune your printer’s exposure settings for your chosen resin.

View Calibration Models

Monocure3D Resin Profiles for SHINING 3D AccuFab Printers

Monocure3D can provide compatible resin recommendations and printer-specific starting profiles for supported SHINING 3D AccuFab dental printers. Profiles are matched to the exact printer, resin, colour, layer height and intended application to provide a safer and more reliable starting point.

Request the correct AccuFab resin profile

Tell us your AccuFab printer model, the Monocure3D resin you intend to use, your preferred layer height and your application. Our team will provide the most appropriate available starting profile and calibration guidance.

Request Resin Settings View Calibration Models

Information to include with your request

  1. Confirm the full SHINING 3D AccuFab printer model.
  2. Provide the Monocure3D resin name and colour.
  3. Tell us the required layer height, such as 50 µm or 100 µm.
  4. Describe the intended dental or laboratory application.
  5. Confirm the version of AccuWare or other printer software being used.
  6. After receiving the profile, complete a calibration print before production use.

Supported AccuFab printer family

AccuFab-Aris

Compact chairside dental printing with a 4K monochrome LCD workflow.

AccuFab-CEL

High-speed dental production using SHINING 3D CPL optical technology.

AccuFab-F1

Professional DLP production for demanding dental and restorative materials.

AccuFab-L4D

Open 4K dental production for models, guides, trays and laboratory workflows.

AccuFab-L4K

Open 4K resin printing for dental and general laboratory applications.

AccuFab-D1s

Legacy DLP platform supported for compatible materials and existing owners.

Important: Recommended profiles are starting points, not guaranteed final settings. Confirm exposure, dimensional accuracy and application suitability with a calibration print. For biocompatible or regulated applications, follow the resin instructions and all applicable washing, post-curing and regional requirements.
