Laboratory Electric Overhead Stirrer with Digital Display | Resin 3D Printer CustomMix Resin Mixer

This laboratory-grade electric overhead stirrer for resin is specifically designed for precise resin mixing in 3D printing. With a digital display and adjustable speed control, it allows you to blend CustomMix additives into base resins with complete accuracy and repeatability.

The overhead design provides efficient, bubble-free mixing for both small and medium resin batches, while the digital readout ensures consistent settings every time. Compatible with both 110V and 220V power, this unit is suitable for global use in labs, workshops, and resin printing studios.

Whether you are creating custom resin formulations, preparing test batches, or standardising production, this stirrer is an essential tool for achieving uniform results and maximising the performance of your 3D printing resins.

Joan Lab Digital Display Overhead Stirrer Mixer Brand name Joanlab Product name overhead stirrer Speedr(RPM) 100 – 2000 1.Overload protection 2.Circuit protection 3.Adjustable speed 4.Time setting

Overhead StirrerTechnical Data
MODEL	OS-10L	OSC-10L	OSC-20L
Maximum amount of stirring(H2O)[L]	10		20
Motor input power[W]	72		200
Motor output power[W]	60		180
Voltage [VAC]	100 – 240
Frequency  [Hz]	50 / 60
Time setting	0 – 999min
Power [W]	80		210
Range of rotate speed [rpm]	100 – 2000
Rotate speed display	/	LCD
Speed display resolution [rpm]	/	+/-1
Speed increment/decrement [rpm]	20
Maximum torque [N.cm]	20		40
Overload protection	Yes
Maximum viscosity [mPas]	10000		30000
Clamping diameter range of drill chuck [mm]	0.5 – 10
Overall dimension (DxWxH) [mm]	200*315*600
Weight [kg]	9		10
DIN EN60529 protection mode	IP42
Allowable ambient temperature [°C]	5 -40
Allowable ambient humidity [%]	80
